Key Feature
-
Intel® Celeron® J4125, Quad-Core 2.0-2.7GHz
-
Dual-Band Frequency 2.4GHz/5GHz WiFi/ 5.0
-
Intel® UHD Graphics 600
-
Dual Gigabit Ethernet
-
IntegratedArd Coprocessor ATSAMD21 ARM® Cortex®-M0+
-
Raspberry Pi 40-Pin Compatible
-
2 x M.2 PCIe (B Key and M Key)
-
Support Windows 10 & Linux OS
-
Compatible with Grove Ecosystem
Description
Edge Computing devices are playing an increasingly important role in the field of IoT. Nowadays, a computer is not just a big rectangular black box under the desk, or a small portable device working on your knees. Computers are ubiquitous devices that span calculating, communicating, and data storage. Based on this definition, here we would like to introduce our new product – theODYSSEY - X86J4125.
ODYSSEY is a series of SBC (Single Board Computer), allowing you to build Edge Computing applications with ease. The ODYSSEY - X86J4125, based on Intel Celeron J4125, is a Quad-Core 2.0GHz CPU that bursts up to 2.7GHz. It includes all the powerful features of Mini PC such as including an 8GB LPDDR4 RAM, 64GB eMMC Storage(optional), onboard Wi-Fi/BLE, Dual Gigabyte Ethernet Ports, Audio Input and Output, USB Ports, HDM1, SATA Connectors and PCIe, however, within a cost-effective price. With simple connections to Mouse, Keyboard and Monitor to ODYSSEY - X86J4125, you will get a Desktop Mini PC right away. With eMMC versions, you even have the Windows 10 Enterprise pre-installed
Just simply connect to a mouse, a keyboard and a monitor with the ODYSSEY – X86J4125, you will get a powerful Desktop Mini PC that can run Windows and Linux OS.
WithDual Gigabit Ethernet, you can build the OpenWrt project and pfSense with ease.
There are alsotwo of M.2 PCIe (B Key and M Key), which enables various expandable capabilities including Hard Drives, SSD, GPU, 4G, and even 5G cellular network connectivity
Comparison Tables of ODYSSEY - X86J4125
|
Model |
CPU |
Core |
Operating System |
Memory |
Fan |
|
ODYSSEY - X86J4125864 |
Intel Celeron J4125 |
4 Core 2.0GHz, Burst to 2.7GHz |
Windows 10 Enterprise (Unactivated) |
64GB eMMC |
Built-in |
|
ODYSSEY - X86J4125864(Win10 Enterprise Activated ) |
Intel Celeron J4125 |
4 Core 2.0GHz, Burst to 2.7GHz |
Windows 10 Enterprise Activated |
64GB eMMC |
Built-in |
|
ODYSSEY - X86J4125800 |
Intel Celeron J4125 |
4 Core 2.0GHz, Burst to 2.7GHz |
No Operating System |
N/A |
N/A |
Specification
|
Components |
ODYSSEY - X86J4125 |
|
Processor |
Intel® Celeron® J4125 (Frequency: 2.0 - 2.7GHz) |
|
Coprocessor |
Microchip® ATSAMD21G18 32-Bit ARM® Cortex® M0+ |
|
Graphics |
Intel® UHD Graphics 600 (Frequency: 250 – 750MHz) |
|
Memory |
LPDDR4 8GB |
|
Wireless |
Wi-Fi 802.11 a/b/g/n/ac @ 2.4/5 GHz HT160 &5.0 |
|
Networking |
Intel® I211AT PCIe Gigabit LAN, Supports Wake-On-LAN, Supports PXE |
|
Audio |
Microphone + headphone Combo Connector |
|
Headers |
1 × 40-Pin header compatible with Raspberry Pi 1 × 28-Pin header (SAMD21G18) 1 × Front Panel Audio Connector 1 × 4-Pin herder (UART function from SAMD21G18) 1 × Fan Port (4 pin 1.25mm PWM 5V) 3 × 4-Pin SATA Power Connector 1 × 4-Pin herder (Power and Switch) |
|
USB |
USB 2.0 Type-A x2, USB 3.1 Type-A x1, USB 3.1 Type-C x1 |
|
Video Interfaces |
HDMI2.0a: Up to 4096x2160 @ 60Hz 24bpp / DP1.2a: Up to 4096x2160 @ 60Hz 24bpp |
|
Expansion Slots |
M.2(Key B, 2242/2280): SATA III, USB2.0, UIM; M.2 (Key M, 2242/2280): PCIe 2.0 ×4; Micro SD card Socket; SIM Card Socket; SATA III |
|
RTC |
JST 1.0 CR2032 3V |
|
TPM |
Built-in TPM (2.0) |
|
Power |
DC Jack 5.5/2.1mm or Type-C PD; DC Jack input: 12-19V DC; Type-C input: 15V DC |
|
Dimensions |
110x110mm |
|
Certifications |
FCC, CE, TELEC |
Applications
-
Mini PC
-
NAS (Network-Attached Storage)
-
Edge Computing
-
Router
-
Robotics
-
Industrial Applications
-
Media Center
-
IT Industry
-
Educational Fields
-
Thin Client
-
Server Cluster
-
IoT Gateway
-
ODYSSEY - X86J4125 x 1
-
User Manual x 1
-
International Power Adapter
-
SATA Cable x 1
-
Antenna x 2
-
RTC Battery x 1
-
Heat Sink(Assembled)
-
Cooling Fan (Assembled) (Included in eMMC versions)
